Advantech EtherCAT Slice IO Smart Power Input Module with 4-ch DI

Deskripsi

Category	Attribute	Value
General	Diagnosis Function	Over/under voltage for input 1&2 Over current output on bus
General	Max Current on Bus	2 A
General	Rated Voltage	24 VDC (±20%)
Hardware	Certification	CE, FCC class A
Hardware	Dual Power Input	Supported
Hardware	LED Indicators	PWR, RUN / ERROR, Power Diagnosis LED
Hardware	Power Consumption	2 W@ 24 VDC
Hardware	Watchdog Timer	1.6 s
Digital Input	Channels	4
Digital Input	Digital Filter	3 ms
Digital Input	Input Delay	From logic level 0 to 1: 4 ms From logic level 1 to 0: 4 ms
Digital Input	Input Voltage	Dry Contact Logic level 1: close to Iso.GND Logic level 0: open Wet Contact Rated voltage: 24 VDC Logic level 1: 10~30 VDC and -10~-30 VDC Logic level 0: -3~3 VDC
Environment	Isolation Voltage	2,000 VDC
Environment	Operating Temperature	-25~60 °C (-14~140 °F)
Environment	Relative Humidity	5~95% RH (non-condensing)
Environment	Storage Temperature	-40~85 °C (-40~185 °F)
EtherCAT	Cycle Time	100 μs
Mechanical	Enclosure	PC + ABS
Mechanical	Mounting	DIN-rail
Mechanical	Weight (Net)	80 g
