Advantech WiFi 2.4G Wireless Sensor Module (WISE-4220-A)
Deskripsi
| Category | Attribute | Value |
| General | Connectors | 1 x Plug-in screw terminal |
| General | Protocol | Modbus/TCP, TCP/IP, UDP, HTTP, DHCP |
| Hardware | Certification | CE, FCC Class A, IC, NCC, SRRC, RCM, VCCI, TELEC |
| Hardware | LED Indicators | Status, Line-power, Wireless Com, Initial/Normal, Signal Strength |
| Hardware | Power Consumption | 1.2 W @ 24 VDC |
| Hardware | Power Input | 10~50 VDC |
| Hardware | Watchdog Timer | 1.6 s |
| Environment | Operating Temperature | -25~70 °C (-13~158 °F) |
| Environment | Relative Humidity | 20~95% RH (non-condensing) |
| Environment | Storage Humidity | 0~95% RH (non-condensing) |
| Environment | Storage Temperature | -40~85 °C (-40~185 °F) |
| Power Requirements | Input Voltage | 10~50 VDC |
| Mechanical | Dimension (W x H x D) | 70 x 102 x 38 mm |
| Mechanical | Enclosure | PC |
| Mechanical | Mounting | DIN-rail, Wall, Pole, Stack |
| Mechanical | Weight (Net) | 0.5 kg |
| Wireless Communication | Frequency Band | IEEE 802.11 b/g/n 2.4 (GHz) |
| Wireless Communication | Standard(Technology) | WIFI |
